Description
Automatic Fire Alarm System for Marine Vessels
Legal Basis: Regulations on the Administration of Seafarer Training of the People's Republic of China (Order No. 5 of the Ministry of Transport, 2019)
Product Category: Basic Safety Training Lab (Z01)
Product Name：Marine fire alarm system
Functional Requirements: Including alarm devices and 2 temperature and smoke detectors each.
Quantity: 1 set of basic safety training room (Z01)
| I. OVERVIEW | ||
| JBS-MA wall-mounted fire alarm controller (marine) is a fire alarm control system designed according to the requirements of the marine fire alarm, the equipment can be equipped with bus-type detection unit can also be equipped with multi-wire detection unit, the product has passed the CCS classification society certification. Fully meet the marine standard requirements of the technical indicators, the host model is divided into wall-mounted, piano table embedded, bus capacity is two circuits of 398 points, multi-wire capacity is 12, the host has a self-diagnostic function, the fire alarm priority under the state of failure, the controller adopts the liquid crystal display in English and Chinese, the menu mode of operation, can be displayed and automatically store a variety of information up to 999 operating. | ||
| II. Performance characteristics: | ||
|
1）Liquid crystal Chinese and English dual display
2) Good human-machine interface(3) Bus and multi-wire can be flexibly selected
4) Considerate and convenient programming design5) Real-time black box recording function
6) Reliable self-diagnostic function and protection function7) Connectable to marine logger, offline programmable
8) Perfect automatic compensation function(9) Selection of different types of detectors to meet the requirements of different uses
|
||
| Technical parameters: | ||
|
1、Working power supply: main power supply: AC220V ±15%/50HZ
Backup battery 12V/10AH two sections
2、System capacity: bus type: two circuits of 398 points; multi-wire type: 12 ways3、Ambient temperature: -10～55℃.4、Environmental humidity: ≤95% (40℃)5、Static power consumption: 220V/500mA6、Contact capacity: DC30V/1A
7、Protection grade: IP20
8, external size: 320mm X 520mm X 115mm
|
